RAB Lighting SR Series LED Strip Light Fixture – Dimmable, Selectable Wattage & Color Temp
RAB Lighting SR Series LED Strip Light Fixture – Dimmable, Selectable Wattage & Color Temp
Specifications
Specifications
| Part Number# | SR |
|---|---|
| Type of Area: | Industrial & Warehouse, Commercial Offices, Retail |
| Color Temp: | Selectable CCT |
| Lamp Life: | 100,000 Hours |
| Lumen Output: | 548 - 12,624 |
| Wattage: | 86 Watt |
| Ballast Start Type: | Instant Start |
| Certifications | 5 Year Warranty, Dimmable, DLC Approved, LM79 / LM80, UL Listed |
| CRI: | 80+ |
| Width: | 2.68" |
| Length: | 24" - 96" |
| Height: | 3.18" |
| Dimmable: | Yes |
| Product Warranty: | 5 year limited warranty |
| Minimum Start Temperature: | -4 Deg F |
| Voltage: | Multivolt 120V-277V |
| Weight Each: | 1.8 - 5.7 lbs. |
| Manufacturer: | RAB Lighting |
| Technology: | LED - New Fixture |
Details
Details
ShineRetrofits Input:
The RAB Lighting SR Series LED Strip Light Fixture delivers versatile, energy-efficient illumination for commercial and industrial spaces. With field-selectable wattage and color temperature options, it provides customizable lighting to suit offices, retail areas, corridors, and warehouses. This dimmable LED strip features an easy-install design and consistent, high-quality output for modern lighting upgrades. Backed by RAB’s 5-year limited warranty, the SR Series ensures long-lasting reliability and excellent energy savings.
Features:
• Available models in 4 sizes and selectable wattages:
SR2: 2 ft (19/15/11/7/4W) 19W default
SR3: 3 ft (30/26/22/18/14W) 30W default
SR4L: 4 ft (28/24/20/16/12W) 28W default
SR4: 4 ft (40/35/30/25/20W) 40W default
SR8: 8 ft (60/52/44/36/28W) 60W default
SR8H: 8 ft (85/75/65/55/45W) 85W default
• Field-adjustable CCT: 3500/4000/5000/5700/6000K (4000K default)
• All models are compatible with Lightcloud Blue-enabled microwave or passive infrared occupancy sensor
• Standard J-Box adapter. V-hooks are optional accessory for suspended mounting and Joiner Kit available for daisy chain use.
• UL Listed for damp locations
• 0-10V dimming
• 50,000-Hour LED lifespan
• 5-Year, limited warranty
